Top Run Spare Part offer parts for XCMG Truck Crane QY16.B5/QY20B.5/QY25K-II, QY50kA. Visit the XCMG parts catalog and send your request for quote.
| Parts list for XCMG Truck Crane QY16.B5/QY20B.5/QY25K-II | Parts list for XCMG Truck Crane QY50KA |
| No. | Part Name | Part Number | No. | Part Name | Part Number |
| 1 | Crank thrust bearing (up) | D02A-111-30 | 1 | Limit switsh | 12102151 |
| 2 | Crank thrust bearing (down) | D02A-323-01c | 2 | Limit switch | 10240024 |
| 3 | Rear cover -plate | D02A-115-01b | 3 | Control manette | 20100418 |
| 4 | Oil seal for crankshaft rear | D02A-118-02b | 4 | Expandion watter tank | 10810027 |
| 5 | Cylinder head case | D04-134-33 | 5 | radiator | 11411759 |
| 6 | Rocker-arm regulating screw | D04-123-31 | 6 | clutch | 10100665 |
| 7 | Filling cap | D04-138-01a | 7 | Hydraulic | 803000260 |
| 8 | Connecting-rod bushing | D05-104-30 | 8 | Hub axle | 799000561l-r |
| 9 | Connecting-rod bolt | D05-105-30 | 9 | Pull pole assembly | 79601349 |
| 10 | Connecting-rod bearing shell | D05-113-31 | 10 | Steer joint assembly | 79900044 |
| 11 | Piston pin | D05-112-01 | 11 | Pin shaft | 79601039 |
| 12 | Generator integrated AC | D11-102-09 | 12 | Steering arm | 80403001 |
| 13 | relay | D11-116-01a | 13 | Brake staff 420x150P | 79601004 |
| 14 | Tensioner fittings | D16A-003-03 | 14 | Brake drum | 79601003 |
| 15 | water strianer parts | D24A-005-30 | 15 | Hub assembly | 79601002 |
| 16 | seal ring for fuel injector | D28-102-800 | 16 | Wheel bolt m20x1.5x52 | 50016001 |
| 17 | Air compressor ass’y | D47-000-27+C | 17 | Wheel nut M20x1.5 | 51017001 |
| 18 | pulley | 12100495 | 18 | Brake arm | 80428003 |
| 19 | Oil cylInder | 11415251 | 19 | Bearing51211E | 54700002 |
| 20 | pulley | 11410789 | 20 | ring | 52020002 |
| 21 | Piston Hydromotor | 12103051 | 21 | Steering arm | 80380002 |
| 22 | pulley | 11410799 | 22 | Right camshaft | 79601051 |
| 23 | Deep-slip ball bearing6016-Z | 10510057 | 23 | Stop ring | 79601024 |
| 24 | pulley | 11412000 | 24 | Bearing 32311 | 54100037 |
| 25 | bearing | 1914/10510033 | 25 | Hub | 79601030 |
| 26 | Cable drum | 11416245 | 26 | Bearing 32315 | 54100040 |
| 27 | Winch motor | 10100883 | 27 | Sealing FB120X150X12 | 53100004 |
| 28 | Winch motor | 10100883 | 28 | Brake drum | 80736010 |
| 29 | Radiator cool | 130500699 | 29 | Brake staff | 84736000 |
| 30 | Tyre rim | 130301499 | 30 | Half shaft | 80736008 |
| 31 | Memory card | D88A-010-800 | 31 | Half shaft | 80736009 |
| 32 | shaft | 135601357 | 32 | Tooth ring | 82468441 |
| 33 | Hydraulic radiator | 803007028 | 33 | Camshaft right | 80736006 |
| 34 | Absorber shock | 819900094 | 34 | Camshaft lift | 80736007 |
| 35 | Multi valve system | 803000071 | 35 | Air room | 55000043 |
| 36 | Power-takeoff |
| 36 | Bracket | 80736004 |
| 37 | Power-takeoff |
| 37 | gear | 82423317 |
| 38 | Power-takeoff |
| 38 | washer | 82423314 |
| 39 | Central shaft | 800300191 | 39 | axle | 82468446 |
| 40 | Clutsh assembly | 800300073 | 40 | Bearing 6212 | 54300001 |
| 41 | Hydraulic cooling radiator | LMF-23051-6A JT | 41 | Oil seal FB 85X105X9 | 53510003 |
| 42 | Solenoid valve | 803000129 | 42 | Oil seal B 85X105X9 | 53510004 |
| 43 | Cable selector | 801300113 | 43 | gear | 82468426 |
| 44 | Oilpressing sensor | 803600329 | 44 | fork | 82468462 |
| 45 | Oilpressing sensor | 803600329 | 45 | Fork block | 82468461 |
| 46 | pulley | 110302284 | 46 | différentiel | 82468409 |
| 47 | pulley | 110700852 | 47 | gear | 82468412 |
| 48 | pulley | 110302221 | 48 | Cross axes | 82423315 |
| 49 | Engine block | SC8DK260Q4 | 49 | Planet gear | 82423316 |
| 50 | Oil pressure sensor | 819908533 | 50 | gear | 82468417 |
| 51 | clutsh | 860122441 | 51 | Wheel bolt | 51018001 |
| 52 | pulley | 111202572 | 52 | Wheel nut | 75502310 |
| 53 | pulley | 111202574 | 53 | Half shaft | 80736008 |
| 54 | pulley | 111202573 | 54 | Half shaft | 80736009 |
| 55 | bearing | 800500170 | 55 | Pinion assembly | 82423307 |
| 56 | bearing | 800500164 | 56 | Bearing 32315 | 54100040 |
| 57 | Bearing hook | 51208 | 57 | Pinion assembly | 82423307 |
| 58 | Slewing hydraulic pump | 803085389 | 58 | Bearing 30312 | 54100043 |
| 59 | Slewing hydraulic pump | 803085389 | 59 | Wheel hub | 83555212 |
| 60 | Height limit switch | 803600733 | 60 | Bearing 32222 | 54100052 |
| 61 | Heigth limit switch | 803600746 | 61 | Bearing 30222 | 54100060 |
| 62 | Wheel wire control assembly | 819908535 | 62 | Lift drag link end | 2307010 |
| 63 | Caution lamp | 803505904 | 63 | Right drag link end | 2307010 |
| 64 | Slewing mechanism | 110700725 | 64 | Tapered roller bearing32314 | GB297-94 |
| 65 | Slewing mechanism | 110700725 | 65 | Tapered roller bearing 32310 | GB297-94 |
| 66 | shaft |
| 66 | Lock ring | 3001013 |
| 67 | Differential assy |
| 67 | Oil seal | 3005010 |
| 68 | differentiel Bearing |
| 68 | Rake camshaft | 3501013BZ |
| 69 | differentiel Bearing |
| 69 | Oil seal | 3501080 |
| 70 | Pelvic angle tooth |
| 70 | bushing | 3501076 A |
| 71 | Pelvic angle tooth |
| 71 | camshaft | 3501040 BZ |
| 72 | Pelvic angle toothbearing |
| 72 | spacer | 3501074 |
| 73 | Reducer housing |
| 73 | Front brake drum | 3501018 B |
| 74 | REAR LAMP LH/RH QY25K-II | 803500054 | 74 | Spring | 3501026 |
| 75 | REAR LAMP LH/RH QY20B.5 | 803500040 | 75 | Axle housing | 2502012 D |
| 76 | REAR LAMP LH/RH QY50KA | 803500040 | 76 | Axle housing | 2502021D |
| 77 | BRAKE LIGHT SWITCH | 803608218 | 77 | Axle housing | 2502051D |
| 78 | CLUTCH EMITTER QY25K-II | 803300377 | 78 | Shifting fork | 2504086 |
| 79 | WINSHILD CABIN REAR QY16B.5 | 189/62 CM | 79 | Spacer bushing | 2502024 |
| 80 | WINSHILD CABIN REAR QY20B.5 | 194/64 CM | 80 | gear | 2502023 D |
| 81 | WINSHILD CABIN REAR QY50KA | 185/70,5CM | 81 | Pinion gear | 2502022 DG |
| 82 | DISTRIBUTOR QY50KA | 803000420 | 82 | Differentiel housing | 2402084 D |
| 83 | LIMIT SWITCH QY20B.5 |
| 83 | Screw collar | 2402100 D |
| 84 | LIMIT SWITCH QY25K-II |
| 84 | flange | 2402078 XJ 3 |
| 85 | FRONT BUMPER QY20B.5 |
| 85 | Screw collar | 2502053 D |
| 86 | FRONT BUMPER QY25K-II |
| 86 | Seal ring | 2402050 D |
| 87 | FRONT BUMPER QY50KA |
| 87 | Seal ring | 2402030 D |
| 88 | HEAD LAMP LH/RH QY20B.5 |
| 88 | Input shaft | 2502061 D |
| 89 | HEAD LAMP LH/RH QY25K-II |
| 89 | bushing | 2502063 D |
| 90 | HEAD LAMP LH/RH QY50KA |
| 90 | Differentiel spider assembly | 2502065 D |
|
|
| 91 | Differential pinion | 2502064 D |
|
|
| 92 | washer | 2502069 D |
|
|
| 93 | bushing | 2502068 D |
|
|
| 94 | Grooved nut | 2502074 D |
|
|
| 95 | Side gear | 2502071 D |
|
|
| 96 | Differential housing | 2502067 D/GB/T276-94 |
|
|
| 97 | Throught shaft 2406B1 XJ 1 | 2500066 XJ 1 |
|
|
| 98 | Oil collector | 2406036 |
|
|
| 99 | Tapered roller bear | 2406100 |
|
|
| 100 | Hub | 2406031 |
|
|
| 101 | Rear axle shaft | 2400031XJ3 |
|
|
| 102 | Support | 2305042B |
|
|
| 103 | Steering oil pump | 10100819 |
|
|
| 104 | radiator | 10100957 |
|
|
| 105 | Revolving tie-in | 10123677 |
|
|
| 106 | Filter with diesel oil crane 25 | D00-305-02+A |
